| DESCRIPTION |
NTSC |
PAL |
| IMAGE SENSOR |
1/3” 2.1 MEGAPIXEL CMOS SENSOR |
| EFFECTIVE PIXEL |
1936 (H) X 1097(V) |
| SCANNING SYSTEM |
Progressive |
| VIDEO OUTPUT |
1 x HD-SDI, 75Ω composite |
| S/N RATIO |
More than 50dB |
| Min. ILLUMINATION |
0.02Lux(SENS-UP x 30) |
| IRIS ADJUSTMENT |
DC / MANUAL |
| LENS |
2.8~12MM DC IRIS MEGAPIXEL LENS(ICR TYPE) |
| ELECTRONIC SHUTTER |
OFF/AUTO(1/30~1/50,000)FLK
MANUAL(x2~x30) |
OFF/AUTO(1/25~1/50,000)FLK
MANUAL(x2~x30) |
| OSD LANGUAGE |
ENG/CHN1/CHN2/JPN |
| BACKLIGHT COMPENSATION |
OFF/BLC/HSBLC |
| DAY & NIGHT |
Auto/ EXT/ B/W(IR SMART) / COLOR |
| AUTO GAIN CONTROL |
LOW / MIDDLE / HIGH / OFF |
| WHITE BALANCE |
AWC→ SET KEY/ MANUAL- BLUE, RED(1~100)/ INDOOR/ OUTDOOR |
| PRIVACY MASKING |
On / Off (Programmable 8 zones) |
| NOISE REDUCTION |
2DNR/3DNR LEVEL(0~100) Adjustment / SMART NR |
| ACCE |
OFF / LOW / MIDDLE / HIGH |
| DEFOG |
Low / Middle / High / Off |
| DIGITAL ZOOM |
OFF/ON(x2 ~x62)/ OFF |
| SENS-UP |
OFF /x2 ~x30 |
| MOTION DETECTION |
3 AREA |
| DIGIAL EFFECT |
OFF / V-FLIP / MIRROR / ROTATE |
| DEFECT |
LIVE DPC(ON, OFF, AUTO) |
| COMMUNICATION |
RS 485(OPTION) |
| IR LED |
30EA |
| INPUT VOLTAGE |
DC 12V(±10%) |
| POWER CONSUMPTION |
IR OFF : 250mA(MAX) / IR ON : 500mA(MAX) |
| OPERATING Temp./Hum. |
-10℃ ~ +50℃ / MAX 90% RH. |
| STORAGE Temp./Hum. |
-20℃ ~ +60℃ / MAX 90% RH. |
